Configuring Transmit and Receive Mode
After you enable LLDP, Dell Force10 systems transmit and receive LLDPDUs by default. You can
configure the system—at CONFIGURATION level or INTERFACE level—to transmit only by executing
the
mode tx command, or receive only by executing the mode rx command. To return to the default setting,
use the
no mode command (Figure 18-14).
Figure 18-14. Configuring LLDPDU Transmit and Receive Mode
R1(conf)#protocol lldp
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
no disable
R1(conf-lldp)#mode ?
rx Rx only
tx Tx only
R1(conf-lldp)#mode tx
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
mode tx
no disable
R1(conf-lldp)#no mode
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
no disable
R1(conf-lldp)#
