Figure 5-1. Using the Order Keyword in ACLs
IP Fragment Handling
FTOS supports a configurable option to explicitly deny IP fragmented packets, particularly second and
subsequent packets. It extends the existing ACL command syntax with the
fragments keyword for all Layer
3 rules applicable to all Layer protocols (permit/deny ip/tcp/udp/icmp).
• Both standard and extended ACLs support IP fragments.
• Second and subsequent fragments are allowed because a Layer 4 rule cannot be applied to these
fragments. If the packet is to be denied eventually, the first fragment would be denied and hence the
packet as a whole cannot be reassembled.
• Implementing the required rules uses a significant number of CAM entries per TCP/UDP entry.
• For IP ACL, FTOS always applies implicit deny. You do not have to configure it.
• For IP ACL, FTOS applies implicit permit for second and subsequent fragments just prior to the
implicit deny.
• If an explicit deny is configured, the second and subsequent fragments do not hit the implicit permit
rule for fragments.
IP Fragments ACL Examples
The following configuration permits all packets (both fragmented & non-fragmented) with destination IP
10.1.1.1. The second rule does not get hit at all (Figure 5-2).
Figure 5-2. Permit All Packets
FTOS(conf)#ip access-list standard acl1
FTOS(conf-std-nacl)#permit 20.0.0.0/8
FTOS(conf-std-nacl)#exit
FTOS(conf)#ip access-list standard acl2
FTOS(conf-std-nacl)#permit 20.1.1.0/24 order 0
FTOS(conf-std-nacl)#exit
FTOS(conf)#class-map match-all cmap1
FTOS(conf-class-map)#match ip access-group acl1
FTOS(conf-class-map)#exit
FTOS(conf)#class-map match-all cmap2
FTOS(conf-class-map)#match ip access-group acl2
FTOS(conf-class-map)#exit
FTOS(conf)#policy-map-input pmap
FTOS(conf-policy-map-in)#service-queue 3 class-map cmap1
FTOS(conf-policy-map-in)#service-queue 1 class-map cmap2
FTOS(conf-policy-map-in)#exit
FTOS(conf)#interface tengig 1/0
FTOS(conf-if-ti-1/0)#service-policy input pmap
FTOS(conf)#ip access-list extended ABC
FTOS(conf-ext-nacl)#permit ip any 10.1.1.1/32
FTOS(conf-ext-nacl)#deny ip any 10.1.1.1./32 fragments
FTOS(conf-ext-nacl)
