240 | Interfaces
www.dell.com | support.dell.com
Figure 13-17. Interface Range Prompt Excluding Duplicate Entries
Exclude a Smaller Port Range
If the interface range has multiple port ranges, the smaller port range is excluded from the prompt.
Figure 13-18. Interface Range Prompt Excluding a Smaller Port Range
Overlap Port Ranges
If overlapping port ranges are specified, the port range is extended to the smallest start port number and
largest end port number.
Figure 13-19. Interface Range Prompt Including Overlapping Port Ranges
Commas
The example below shows how to use commas to add different interface types to the range, enabling all
Ten Gigabit Ethernet interfaces in the range 5/1 to 5/23 and both Ten Gigabit Ethernet interfaces 1/1 and 1/
2.
Figure 13-20. Multiple-Range Bulk Configuration Gigabit Ethernet and Ten-Gigabit Ethernet
Add Ranges
The example below shows how to use commas to add VLAN and port-channel interfaces to the range.
FTOS(conf)#interface range vlan 1 , vlan 1 , vlan 3 , vlan 3
FTOS(conf-if-range-vl-1,vl-3)#
FTOS(conf)#interface range tengigabitethernet 2/0 - 23 , tengigabitethernet 2/0 - 23 , tengigab 2/0 - 23
FTOS(conf-if-range-te-2/0-23)#
FTOS(conf)#interface range tengigabitethernet 2/0 - 23 , tengigab 2/1 - 10
FTOS(conf-if-range-te-2/0-23)#
FTOS(conf)#inte ra tengig 2/1 - 11 , tengig 2/1 - 23
FTOS(conf-if-range-te-2/1-23)#
FTOS(conf-if)# interface range tengigabitethernet 5/1 - 23, tengigabitethernet 1/1 - 2
FTOS(conf-if-range-te-5/1-23)# no shutdown
FTOS(conf-if-range-te-5/1-23)#
