Link Aggregation Control Protocol (LACP) | 295
Figure 16-10. LACP Sample Topology
Configuring a LAG on ALPHA
Figure 16-11 shows creating a LAG (ALPHA).
Figure 16-11. Creating a LAG on ALPHA
Alpha(conf)#interface port-channel 10
Alpha(conf-if-po-10)#no ip address
Alpha(conf-if-po-10)#switchport
Alpha(conf-if-po-10)#no shutdown
Alpha(conf-if-po-10)#show config
!
interface Port-channel 10
no ip address
switchport
no shutdown
!
Alpha(conf-if-po-10)#
