Dell Force10 MXL Blade - Command History; Filtering Show Command Outputs

Configuration Fundamentals | 33
Command History
FTOS maintains a history of previously-entered commands for each mode. For example:
• When you are in EXEC mode, the UP and DOWN arrow keys display the previously-entered EXEC
mode commands.
• When you are in CONFIGURATION mode, the UP or DOWN arrows keys recall the
previously-entered CONFIGURATION mode commands.
Filtering show Command Outputs
Filter the output of a show command to display specific information by adding | [except | find | grep | no-more
| save]
specified_text after the command. The variable specified_text is the text for which you are filtering and
it IS case sensitive unless you use the
ignore-case sub-option.
The
grep command accepts an ignore-case sub-option that forces the search to be case-insensitive. For
example, the commands:
• show run | grep Ethernet returns a search result with instances containing a capitalized “Ethernet,” such
as interface TenGigabitEthernet 0/0.
•
show run | grep ethernet would not return that search result because it only searches for instances
containing a non-capitalized “ethernet.”
Executing the
show run | grep Ethernet ignore-case command would return instances containing both
“Ethernet” and “ethernet.”
•
grep displays only the lines containing specified text. Figure 2-9 shows this command used in
combination with the
do show stack-unit all stack-ports pfc details | grep 0 command.
Figure 2-9. Filtering Command Outputs with the grep Command
Note: FTOS accepts a space or no space before and after the pipe. To filter on a phrase with spaces,
underscores, or ranges, enclose the phrase with double quotation marks.
FTOS(conf)#do show stack-unit all stack-ports all pfc details | grep 0
stack unit 0 stack-port all
0 Pause Tx pkts, 0 Pause Rx pkts
0 Pause Tx pkts, 0 Pause Rx pkts
0 Pause Tx pkts, 0 Pause Rx pkts
0 Pause Tx pkts, 0 Pause Rx pkts
0 Pause Tx pkts, 0 Pause Rx pkts
0 Pause Tx pkts, 0 Pause Rx pkts
