532 | Simple Network Management Protocol (SNMP)
www.dell.com | support.dell.com
Create a VLAN
Use the dot1qVlanStaticRowStatus object to create a VLAN. The snmpset operation in Figure 30-16
creates VLAN 10 by specifying a value of 4 for instance 10 of the dot1qVlanStaticRowStatus object.
Figure 30-16. Creating a VLAN Using SNMP
Assign a VLAN Alias
Write a character string to the dot1qVlanStaticName object to assign a name to a VLAN as shown in
Figure 30-17.
Figure 30-17. Assign a VLAN Alias Using SNMP
> snmpset -v2c -c mycommunity 123.45.6.78 .1.3.6.1.2.1.17.7.1.4.3.1.5.10 i 4
SNMPv2-SMI::mib-2.17.7.1.4.3.1.5.10 = INTEGER: 4
[Unix system output]
> snmpset -v2c -c mycommunity 10.11.131.185 .1.3.6.1.2.1.17.7.1.4.3.1.1.1107787786 s "My
VLAN"
SNMPv2-SMI::mib-2.17.7.1.4.3.1.1.1107787786 = STRING: "My VLAN"
[FTOS system output]
FTOS#show int vlan 10
Vlan 10 is down, line protocol is down
Vlan alias name is: My VLAN
Address is 00:01:e8:cc:cc:ce, Current address is 00:01:e8:cc:cc:ce
Interface index is 1107787786
Internet address is not set
MTU 1554 bytes, IP MTU 1500 bytes
LineSpeed auto
ARP type: ARPA, ARP Timeout 04:00:00
Last clearing of "show interface" counters 01:01:00
Queueing strategy: fifo
Time since last interface status change: 01:01:00
