640 | Virtual Router Redundancy Protocol (VRRP)
www.dell.com | support.dell.com
To configure the VRRP group’s priority, use the following command:
Figure 38-7. priority Command Example
Figure 38-8. show vrrp Command Example
Configure VRRP Authentication
Simple authentication of VRRP packets ensures that only trusted routers participate in VRRP processes.
When you enable authentication, FTOS includes the password in its VRRP transmission, and the receiving
router uses that password to verify the transmission.
Task Command Syntax Command Mode
Configure the priority for the VRRP
group.
Range: 1 to 255
Default: 100
priority priority INTERFACE -VRID
Note: You must configure all virtual routers in the VRRP group at the same: authentication must be
enabled with the same password or authentication is disabled.
FTOS(conf-if-te-1/2)#vrrp-group 111
FTOS(conf-if-te-1/2-vrid-111)#priority 125
FTOS#show vrrp
------------------
Tengigabitethernet 1/1, VRID: 111, Net: 10.10.10.1
State: Master, Priority: 255, Master: 10.10.10.1 (local)
Hold Down: 0 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Bad pkts rcvd: 0, Adv sent: 2343, Gratuitous ARP sent: 5
Virtual MAC address:
00:00:5e:00:01:6f
Virtual IP address:
10.10.10.1 10.10.10.2 10.10.10.3 10.10.10.10
Authentication: (none)
------------------
Tengigabitethernet 1/2, VRID: 111, Net: 10.10.2.1
State: Master, Priority: 125, Master: 10.10.2.1 (local)
Hold Down: 0 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Bad pkts rcvd: 0, Adv sent: 601, Gratuitous ARP sent: 2
Virtual MAC address:
00:00:5e:00:01:6f
Virtual IP address:
10.10.2.2 10.10.2.3
Authentication: (none)
FTOS(conf)#
