Figure 19-12. Router 2 Running-configuration
protocol spanning-tree mstp
no disable
name Tahiti
revision 123
MSTI 1 VLAN 100
MSTI 2 VLAN 200,300
!
interface TenGigabitEthernet 2/11
no ip address
switchport
no shutdown
!
interface TenGigabitEthernet 2/31
no ip address
switchport
no shutdown
!
interface Vlan 100
no ip address
tagged TenGigabitEthernet 2/11,31
no shutdown
!
interface Vlan 200
no ip address
tagged TenGigabitEthernet 2/11,31
no shutdown
!
interface Vlan 300
no ip address
tagged TenGigabitEthernet 2/11,31
no shutdown
Set Region Name and Revision
Map MSTP Instances to VLANs
Assign Layer-2 interfaces
to MSTP topology
Create VLANs mapped to MSTP Instances
Tag interfaces to VLANs
Enable MSTP globally
