To configure a virtual IP address, follow these steps:
Figure 38-4. virtual-address Command Example
Figure 38-5. show config Command Example
Step Task Command Syntax Command Mode
1 Configure a VRRP group.
VRID Range: 1 to 255
vrrp-group vrrp-id INTERFACE
2 Configure virtual IP addresses
for this VRID.
Range: up to 12 addresses
virtual-address ip-address1 [...ip-address12] INTERFACE -VRID
FTOS(conf-if-te-1/1-vrid-111)#virtual-address 10.10.10.1
FTOS(conf-if-te-1/1-vrid-111)#virtual-address 10.10.10.2
FTOS(conf-if-te-1/1-vrid-111)#virtual-address 10.10.10.3
FTOS(conf-if-te-1/1-vrid-111)#
FTOS(conf-if-te-1/1)#show conf
!
interface Tengigabitethernet 1/1
ip address 10.10.10.1/24
!
vrrp-group 111
priority 255
virtual-address 10.10.10.1
virtual-address 10.10.10.2
virtual-address 10.10.10.3
!
vrrp-group 222
no shutdown
FTOS(conf-if-te-1/1)#
Note that the Primary IP address
and the Virtual IP addresses are
on the same subnet
