• If the TTL field has a value other than zero, the receiving LLDP agent is notified to completely
replace all information associated with the LLDP agent or port with the information in the
received LLDPDU.
• If the TTL field value is zero, the receiving LLDP agent is notified that all system information
associated with the LLDP agent or port is to be deleted. This TLV may be used, for example, to
signal that the sending port has initiated a port shutdown procedure.
The LLDPDU format is shown in “LLDPDU packet format” on page 256.
The TTL TLV format is shown below.
FIGURE 19 TTL TLV packet format
MIB support
Brocade devices support the following standard MIB modules:
• LLDP-MIB
• LLDP-EXT-DOT1-MIB
• LLDP-EXT-DOT3-MIB
Syslog messages
Syslog messages for LLDP provide management applications with information related to MIB data
consistency and general status. These Syslog messages correspond to the lldpRemTablesChange
SNMP notifications.
Web Management
<<Not currently supported>>
Configuring LLDP
This section describes how to enable and configure LLDP.
Table 61 lists the LLDP global-level tasks and the default behavior/value for each task.
TLV Type = 3 TLV Information
String Length = 2
Time to Live (TTL)
7 bits 9 bits 2 octets
