BigIron RX Series Configuration Guide 445
53-1002253-01
Displaying VSRP information
15
BigIron RX# show vsrp brief
VLAN VRID ConfPri CurPri P State PeerMacAddr or IpAddress VIP
10 10 100 80 P Master Unknown Unknown None
When the command is entered on a Layer 3 VSRP, it displays the following information.
BigIron RX# show vsrp brief
VLAN VRID ConfPri CurPri P State PeerMacAddr or IpAddress VIP
100 1 150 1 P Initia xxxx.1414.1404 20.20.20.4 20.20.20.100
101 2 50 1 P Initia xxxx.1e1e.1e01 30.30.30.1 30.30.30.100
Syntax: show vsrp brief
Displaying VSRP packet statistics for VSRP
When Layer 3 VSRP is enabled, you can enter the following command to display VSRP statistics.
BigIron RX# show vsrp statistics
Global VSRP statistics
----------------------
- received packets with checksum errors = 0
- received packets with invalid version number = 0
- received packets with unknown or inactive vrid = 43
To display VSRP statistics for a specific VLAN, enter a command such as the
following:
BigIron RX# show vsrp statistics vlan 100
This field... Displays...
VLAN The VLAN on which VSRP is configured.
VRID The VRID for which the following information is displayed.
ConfPri The configured priority for the device’s preferability for becoming the Master
for the VRID.
CurPri The device’s current priority for becoming the Master.
P Pre-empt mode status:
• P – pre-emption is enabled for the VLAN
• N – pre-emption is disabled for the VLAN
state This device’s VSRP state for the VRID. The state can be one of the following:
• initialize – VSRP is not enabled on the VRID. If the state remains
“initialize” after you enable VSRP on the VRID, make sure that the VRID
is also configured on the other routers and that the routers can
communicate with each other.
NOTE: If the state is “initialize” and the mode is incomplete, make sure you
have specified the IP address for the VRID.
• standby – This device is a Backup for the VRID.
• master – This device is the Master for the VRID.
Peer MAC address or IP address MAC address or IP address of the peer.
VIP Virtual IP address for the VLAN.
