Displaying MBGP information
27
Displaying MBGP neighbors
To view MBGP neighbor information including the values for all the configured parameters, enter
the following command. This display is similar to the show ip bgp neighbor display but has
additional fields that apply only to MBGP. These fields are shown in bold type in the example and
are explained below.
The display shows all the configured parameters for the neighbor. Only the parameters that have
values different from their defaults are shown.
This example shows how to display information for a specific neighbor, by specifying the neighbor’s
IP address with the command. The number in the far left column indicates the neighbor for which
information is displayed. When you list information for multiple neighbors, this number makes the
display easier to read.
The Neighbor NLRI Negotiation section (shown in bold type) lists the types of routes that this device
can exchange with the MBGP neighbor.
The TCP statistics at the end of the display show status for the TCP session with the neighbor. Most
of the fields show information stored in the device’s Transmission Control Block (TCB) for the TCP
session between the device and its neighbor. These fields are described in detail in section 3.2 of
RFC 793, “Transmission Control Protocol Functional Specification”.
Syntax: show ip mbgp neighbors [<ip-addr>]
BigIron RX # show ip mbgp neighbor 7.7.7.2
Total number of BGP Neighbors: 1
1 IP Address: 166.1.1.2, Remote AS: 200 (IBGP), RouterID: 8.8.8.1
State: ESTABLISHED, Time: 0h33m26s, KeepAliveTime: 60, HoldTime: 180
KeepAliveTimer Expire in 9 seconds, HoldTimer Expire in 161 seconds
PeerGroup: mbgp-mesh
MD5 Password: $Gsig@U\
NextHopSelf: yes
RefreshCapability: Received
Messages: Open Update KeepAlive Notification Refresh-Req
Sent : 2 3264 17 0 0
Received: 1 1 34 0 0
Last Update Time: NLRI Withdraw NLRI Withdraw
Tx: --- --- Rx: --- ---
Last Connection Reset Reason:Unknown
Notification Sent: Unspecified
Notification Received: Unspecified
Neighbor NLRI Negotiation:
Peer Negotiated IPV4 multicast capability
Peer configured for IPV4 multicast Routes
TCP Connection state: ESTABLISHED, MD5-Password: ********
TTL check: 0, value: 0, rcvd: 64
Byte Sent: 284418, Received: 767
Local host: 166.1.1.1, Local Port: 179
Remote host: 166.1.1.2, Remote Port: 8137
ISentSeq: 2763573 SendNext: 3047992 TotUnAck: 0
TotSent: 284419 ReTrans: 0 UnAckSeq: 3047992
IRcvSeq: 3433336 RcvNext: 3434104 SendWnd: 65000
TotalRcv: 768 DupliRcv: 0 RcvWnd: 65000
SendQue: 0 RcvQue: 0 CngstWnd: 1440
