Displaying OSPF information
25
Displaying OSPF area information
To display OSPF area information, enter the following command at any CLI level.
Syntax: show ip ospf area [<area-id>] | [<num>]
The <area-id> parameter shows information for the specified area.
The <num> parameter displays the entry that corresponds to the entry number you enter. The entry
number identifies the entry’s position in the area table.
This display shows the following information.
PC current instruction for the task
Stack Stack location for the task
Size Stack size of the task
CPU Usage(%) Percentage of the CPU being used by the task
task id Task’s ID number assigned by the operating system.
task vid A memory domain ID.
TABLE 113 CLI display of OSPF area information
This field... Displays...
Indx The row number of the entry in the router’s OSPF area table.
Area The area number.
Type The area type, which can be one of the following:
• nssa
• normal
• stub
Cost The area’s cost.
SPFR The SPFR value.
ABR The ABR number.
ASBR The ABSR number.
LSA The LSA number.
Chksum(Hex) The checksum for the LSA packet. The checksum is based on all the
fields in the packet except the age field. The device uses the checksum
to verify that the packet is not corrupted.
TABLE 112 CLI display of show tasks (Continued)
This field... Displays...
BigIron RX> show ip ospf area
Indx Area Type Cost SPFR ABR ASBR LSA Chksum(Hex)
1 0.0.0.0 normal 0 1 0 0 1 0000781f
2 192.147.60.0 normal 0 1 0 0 1 0000fee6
3 192.147.80.0 stub 1 1 0 0 2 000181cd
