S-14
(2) Adjust
Function Purpose Setting Details/Precautions
PRN
MAIN
REGIST
TEST
COPY
To vary and adjust the print start
position in the main scanning
direction.
✽ If the image on the copy devi-
ates in the CD direction
✽ When the PH unit has been
replaced
Press the Start key to begin
printing the test page.
ADJUST
The setting range is 60 to 140.
(1 increment = 0.1 mm)
PRN
SUB
REGIST
TEST
COPY
To vary and adjust the print start
position in the sub-scanning direc-
tion.
✽ If the image on the copy devi-
ates in the FD direction
✽ When the PH unit has been
replaced
Press the Start key to begin
printing the test page.
ADJUST
The setting range is 87 to 113.
(1 increment = 0.46 mm)
CCD
MAIN
ZOOM
TEST
COPY
To adjust for variations in the accu-
racy of IR parts and their mounting
accuracy by varying the scanning
zoom ratio in the main scanning
direction.
✽ When the Timing Belt has been
replaced
✽ When the Scanner Assy. has
been replaced
Press the Start key to begin
printing the test page.
ADJUST
The setting range is 95 to 105.
(1 increment = 0.4%)
CCD
SUB
ZOOM
TEST
COPY
To adjust for variations in the accu-
racy of IR parts and their mounting
accuracy by varying the scanning
zoom ratio in the sub-scanning
direction.
✽ When the Scanner Assy. has
been replaced
Press the Start key to begin
printing the test page.
ADJUST
The setting range is 95 to 105.
(1 increment = 0.4%)
CCD
MAIN
REGIST
TEST
COPY
To adjust for variations in the accu-
racy of IR parts and their mounting
accuracy by varying the scanning
start position in the main scanning
direction.
✽ When the Upper Cover Assy.
(Original Glass) has been
replaced
✽ When the Scanner Assy. has
been replaced
Press the Start key to begin
printing the test page.
ADJUST
The setting range is 90 to 110.
(1 increment = 0.5 mm)
