Diatron Abacus 5 - User Maintainable Parts

115
Figure 86. Self Test Panel
Initiating a self test will test the key functions and components of the analyzer. The process takes approximately one
minute. The individually tested items and their acceptable ranges can be found in the following table. Clicking or
tapping any of the individual test items provides detailed information including the item readings, limits and
comments.
Clicking or tapping the ‘Load last selftest’ button lets you view the results of the previous self test for comparison.
Big and small buffer times for 0 to 1,000m (0 to 1,380 ft.) Altitude
Big buffer time
Small buffer time
Generate
3,000 to 12,000 ms
Generate 1
1,200 to 2,800 ms
Release
3,000 to 6,000 ms
Generate 2
1,200 to 2,800 ms
Release
700 to 1,300 ms
Big and small buffer times for 1,000 to 2,000m (3,280 to 6,560 ft.) Altitude
Big buffer time
Small buffer time
Generate
3,000 to 16,800 ms
Generate 1
1,200 to 3,640 ms
Release
3,000 to 7,200 ms
Generate 2
1,200 to 3,640 ms
Release
700 to 1,560 ms
Big and small buffer times for greater than 2,000m (6,560 ft.) Altitude
Big buffer time
Small buffer time
Generate
3,000 to 26,400 ms
Generate 1
1,200 to 5,040 ms
Release
3,000 to 10,200 ms
Generate 2
1,200 to 5,040 ms
Release
700 to 2,210 ms
Big buffer drift
Small buffer drift
Maximum
540 to 560 mbar
Maximum
225 to 235 mbar
Minimum
530 to 560 mbar
Minimum
215 to 235 mbar
Drift
-5 to +15 mbar
Drift
-5 to +15 mbar
Max vacuum P1
Max vacuum P2
Maximum
550 to 1,000 mbar
Maximum
500 to 1,000 mbar
Time
0 to 6,000 ms
Time
0 to 6,000 ms
Pump Status
Null pressures
Pump1
1 to 1
Sheath
-20 to +20 mbar
Pump2
1 to 1
Capillary
-20 to +20 mbar
Chamber
-20 to +20 mbar
Noise/pulse
HGB head
pls/8sec
0 to 20 pulses
HGB dark
0 to 3,000 pulses
20000 pulses
19,990 to 20,050 pulses
HGB light
3,000 to 60,000 pulses
TCU temperature
Laser parameters
Actual
Reference  0.2C (0.35F)
Reference
 10%
Sink
0 to 70C (32 to 158F)
Laser Power
32 to 128
Laser DC Level
Reagent lock
Laser off
0.00 to 0.05 mV
Status
UNLOCKED / LOCKED / NA
Laser on
0.05 to 0.65 mV
Available
measurements
No specification
Electrode
Battery/Power Supply
Voltage
45 to 55 V
Battery Voltage
0.0 to 3.5 V
Current
620 to 680 A
+12V
11.4 to 13.0 V
