Diatron Abacus 5 - Long, Smeared Population; Figure 109. Smeared Population

140
Go to Main Menu, and click or tap the ‘Maintenance’ button. Click or tap the ‘Hard cleaning’ button in the
Cleaning section to initiate the procedure. You will need a syringe (10ml) to dose cleaning liquid into the
analyzer’s measuring chambers. The process is described below.
20.4.2 Long, smeared population
A long, smeared population with this appearance shows that a key
part of the measurement process is not operating as expected.
This could be the TCU, the reagents or the sample mixing. Possible
root causes are:
 The two lyse reagents are interchanged
 Check tube connections or container connections
Figure 109. Smeared
Population
