42
Figure 21. ‘Abacus 5’ Main Menu
6.7.7 Autosampler Control Panel
If you have an optional Autosampler installed, the Autosampler control panel can be opened by double
clicking/tapping the Autosampler status on the left side of the status display on the bottom of the screen. The
Autosampler control panel allows you to see of the Autosampler is operational and perform an Autosampler
initialization.
See section 8.4.2.6 for more information about the Autosampler control panel.
6.7.8 Adjust the Time and Date
Double click/tap the time display on the right side of the status display on the bottom of the screen to bring up a
panel for adjusting the stored time and date of the ‘Abacus 5’ analyzer. See section 6.7.8 for more information about
time and date adjustment.
6.7.9 Open the Warning Panel
If an error or warning is currently active, an exclamation point icon appears on the status display. Click the icon to
review the active error or warning and jump to the appropriate menu where the error or warning can be addressed
(such as reagent replacement).
6.7.10 Menu Tree
The following is a listing of the ‘Abacus 5’ analyzer main menu tree:
Patient
New: Add a new patient
Edit: Modify an individual patient’s information
Details: View an individual patient’s information
See section 1 for more information about patient data
Exit
Cancel: Cancels shutdown of the ‘Abacus 5’ analyzer
