digico D5T - 1.2 Hardware Configuration

Chapter 1
1-4
1.2 Hardware Configuration
1.2.1 Connections .........................................................................
Detailed information on the various systems of connection is provided in the Interconnection and System Setup Manual but the
following diagram provides an overview of a single console setup.
For Multiple Console Setups see Appendix B
STAGE RACKS
CONNECTION WITH OPTICAL FIBRE
OPTO A
OPTO ID 30
OPTO ID 20
FOH
AUDIO SYNC = OPTO
OPTO ID 32
OPTO A
OPTIONAL
REDUNDANT
LOOP
OPTO A
OPTO B
OPTO B
OPTO B
MAIN MADI IN
LOCAL RACK
MAIN MADI OUT
MADI
PORT 2 IN
MADI
PORT 2 OUT
MAIN MADI IN
CONNECTION WITH MADI
MAIN MADI IN
STAGE RACKS
MADI PORT 1 OUT MADI PORT 3 OUT
MADI
PORT 2 OUT
MADI PORT 1 IN MADI PORT 3 IN
MAIN MADI OUT MAIN MADI OUT
FOH
AUDIO SYNC = MASTER
MAIN MADI IN
LOCAL RACK
MAIN MADI OUT
MADI
PORT 2 IN
MADI
PORT 2 OUT
