Chapter 1
1-7
Input Channel
Routing Module
EQ Module
Dynamics Module
Aux / Pan Module
Input Module
Analogue Gain
Digital Trim
Input Gain
Phase
Aux Send & Compressor Controls
Screen Scroll
Assign Rotary
Assign Button
Channel Fader
LCD Function
Aux Send & Gate Controls
Mute
Interactive LCD Button
Aux On/Off & Compressor Controls
Aux On/Off & Gate Controls
Assigned Rotary Level
Assigned Button On/Off
Master Screen
