3-10
Chapter 3
To Route a Matrix Group to a pre EQ, pre fader Direct Output:
1) Touch the bottom of the matrix group screen to open the routing panel.
2) Touch the Direct button if it is not already highlighted.
3) Touch the name of the Socket Group to view the output socket names.
4) Touch the Output Socket button(s) that you require eg. Loc op 1, Loc op 2 etc.
5) Touch the bottom of the input screen again to return to the standard view.
6) Touch the Direct On button to turn the output on.
2
3
4
1 5
6
