Ducati SS 800 - Colors; Transmission; Timing;valves

Caratteristiche tecniche
Specifications
sezione / section
C 1.1
10
A
B
C
D
E
F
G
H
L
M
N
P
SuperSport 800 - M.Y. 2006 - edizione/edition 00
Colors
Transmission
Timing/valves
Description Code
Ducati Anniversary Red
red frame
black wheel rims
F_473.101 (PPG)
Reference Technical specifications
Clutch Wet multi-plate clutch
Clutch control Hydraulic
Gearbox Six gears
Primary drive 33/61
Transmission ratio 1.85
Final drive 15/39
Gearbox type Constant mesh spur gears, controlled by gear
change lever on vehicle left side
Gear ratios
1
st
2
nd
3
rd
4
th
5
th
6
th
13/32
18/30
21/28
23/26
22/22
26/24
Reference Standard value Max. allowed value
Timing diagram With 1 mm valve clearance
Intake Opening 19° B.T.D.C.
Closing 60° A.B.D.C.
Exhaust Opening 56° B.B.D.C.
Closing 24° A.T.D.C.
Intake valve diameter
Exhaust valve diameter
43 mm
38 mm
Valve lift With 0 mm valve clearance Intake 10.8 mm
Exhaust 10.3 mm
Opening rocker arm - intake 0.10-0.15 mm 0.10-0.20 mm
Opening rocker arm - exhaust 0.10-0.15 mm 0.10-0.20 mm
Closing rocker arm - intake 0-0.05 mm 0.05-0.10 mm
Closing rocker arm - exhaust 0-0.05 mm 0.05-0.10 mm
Belt
tensioning
145 Hz (horizontal) ± 5Hz
160 Hz (vertical) ± 5Hz
145 Hz (horizontal) ± 5Hz
160 Hz (vertical) ± 5Hz
Idle speed adjustment 1250 ± 50 rpm
