3 - TORQUE SETTINGS
Frame torque settings
Part Thread (mm) Nm tolerance ±10% Notes
Chain, front sprocket
Front sprocket retaining screw M 5x0.8 6 * LOCK 1
Front sprocket guard screw M 6x1 6
Light units
Tail light retaining screw M 5x0.8 5
Headlight holder retaining screw M 6x1 8
Number plate holder nut M 6x1 4
Turn indicator nut M 6x1 3.2
Number plate light nut M 5x0.8 1.5
Screw securing tail light to grab handle M 4x0.7 2.5
Screw securing headlight support to frame
tube
M 8x1.25 24
Cat's eye nut M 4x0.7 1 mm
Screw securing headlight support to frame M 6x1 9
Instrument panel
Connector nut M 5x0.8 4
Instruments nut M 5x0.8 4
Front fork
Steering bearings ring nut M 25x1 12 GREASE A
Limit stop lock nut M 8x1.25 18 LOCK 2 only on nut
thread
Steering plug M 20x1.5 12 GREASE D
Steering head screws securing fork legs M 10x1.5 37 * GREASE B
Steering head screws securing shaft M 8x1.25 23 * GREASE B
Bottom yoke screw M 8x1.25 20 GREASE B - sequence
1-2-1
Fork bottom end bolt M 8x1.25 19 GREASE B - sequence
1-2-1
Electrical system
Speed sensor retaining screw M 6x1 10
Starter motor nut M 6x1 5 GREASE B
Key-operated switch bolt M 6x1 9 LOCK 1
Right and left switch screw M 5x0.8 3.5
Horn mount nut M 12x1 20
Nut securing cables to solenoid starter M 6x1 4
Control unit retaining screw M 6x1 9
Screw securing coil unit to frame M 6x1 9
Regulator-to-frame retaining screw M 6x1 9
Nut securing control unit support to filter box M 5x0.8 5
Coil cable guide nut M 6x1 10
Coil-to-support retaining screw M 5x0.8 3
