Ducati SS 800 - Lubrication system; Cylinder; piston

Caratteristiche tecniche
Specifications
sezione / section
C 1.1
11
A
B
C
D
E
F
G
H
L
M
N
P
SuperSport 800 - M.Y. 2006 - edizione/edition 00
Lubrication system
Cylinder / piston
Reference Standard value Max. allowed value
Circuit and engine oil capacity 3.3 liters
Oil pump Capacity 4.0 liters/rpm
Gear backlash 0.10 mm
Radial clearance between gears
and pump body
0.10 mm
Axial clearance between gears and
pump body
0.10 mm
Axial clearance between gears and
cover
0.07 mm
Oil pressure Oil temperature = 80°
1100 - 1300 rpm
3500-4000 rpm
over 0.8 bar
over 4 bar
6
Reference Design value Wear limit
Cylinder Max. oval 0.03 mm
Max. taper 0.03 mm
Rated diameter
class A
class B
class C
88.000 mm
88.010 mm
88.020 mm
0-0.01 mm
0-0.01 mm
0-0.01 mm
Piston Rated diameter
class A
class B
class C
87.970 mm
87.980 mm
87.990 mm
0 - 0.005 mm
0 - 0.005 mm
0 - 0.005 mm
Piston outer diameter
measured at 6.0 mm from
piston skirt
88.00 mm 0.010 mm
Connecting rod Rated con-rod big-end
diameter
ø42 mm
Gudgeon pin-piston
clearance
0.004-0.012 mm 0.025 mm
Piston-cylinder coupling
clearance
0.030 - 0.050 mm 0.12 mm
Gudgeon pin-connecting
rod clearance
0.006 - 0.028 mm 0.005 mm
Con-rod bearings-crankpin
coupling clearance
0.015 - 0.058 mm
Cylinder compression Standard
Minimum
Max. allowed difference
11 - 12 bar
10 bar
2 bar
