Caratteristiche tecniche
Specifications
sezione / section
C 3
30
A
B
C
D
E
F
G
H
L
M
N
P
SuperSport 800 - M.Y. 2006 - edizione/edition 00
*
critical point for dynamic safety. Tightening torque tolerance must be: ± 5% Nm.
Note
For product specifications and symbols, refer to “Product specifications” (Section A2).
Rocker arm shaft cover screws M 6x1 10 9 11
Intake / exhaust valve cover screws M 6x1 10 9 11
Casing jointing screws M 6x1 9 8.5 9.5
Clutch cover screws M 6x1 9 8.5 9.5
Generator cover screws M 6x1 10 9 11
Clutch spring screws M 5x0.8 5
*
57GREASE A
Manifold nipple M 5x0.8 3
*
2 3 LOCK 2 or
THREE BOND 1324
Split belt roller flange retaining screws M 5x0.8 5
*
57
Head cover plug M 5x0.8 2.5
*
2.5 3
Screws M 10x1.5 45 40 50
Screws M 8x1.25 25 22 28
Screws M 6x1 10 9 11
Screws M 5x1 5
*
57
Part Thread (mm) Nm Min. Max. Notes
