Chapter 12
| Power over Ethernet Commands
– 379 –
â—† If a device is connected to a switch port after bootup and the switch detects
that it requires more than the power budget set for the port or for the overall
switch, no power is supplied to the device regardless of its priority setting.
Example
Console(config)#interface ethernet 1/1
Console(config-if)#power inline priority 2
Console(config-if)#
show power inline
status
This command displays the current power status for all ports or for specific ports.
Syntax
show power inline status [interface]
interface
ethernet
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-12/24)
Command Mode
Privileged Exec
Example
Console#show power inline status
Unit: 1
Compatible mode : Enabled
Time Max Used
Interface Admin Range Oper Power Power Priority
--------- -------- -------- ---- -------- -------- --------
Eth 1/ 1 Enabled -- Off 34200 mW 0 mW Low
Eth 1/ 2 Enabled -- Off 34200 mW 0 mW Low
Eth 1/ 3 Enabled -- Off 34200 mW 7505 mW Low
Eth 1/ 4 Enabled -- Off 34200 mW 0 mW Low
Eth 1/ 5 Enabled -- Off 34200 mW 0 mW Low
Eth 1/ 6 Enabled -- Off 34200 mW 0 mW Low
Eth 1/ 7 Enabled -- Off 15400 mW 8597 mW Low
Eth 1/ 8 Enabled -- Off 15400 mW 0 mW Low
Eth 1/ 9 Enabled -- Off 15400 mW 0 mW Low
Eth 1/10 Enabled -- Off 15400 mW 0 mW Low
Eth 1/11 Enabled -- Off 15400 mW 0 mW Low
Eth /12 Enabled -- Off 15400 mW 0 mW Low
.
.
.
Table 75: show power inline status - display description
Field Description
Admin The power mode set on the port (see power inline)
Oper The current operating power status (displays on or off)
