Chapter 22
| Multicast Filtering Commands
Multicast VLAN Registration
– 583 –
Command Mode
Global Configuration
Command Usage
â—† Use this command to statically configure all multicast group addresses that will
join the MVR VLAN. Any multicast data associated an MVR group is sent from all
source ports to all receiver ports that have registered to receive data from that
multicast group.
â—† The IP address range from 224.0.0.0 to 239.255.255.255 is used for multicast
streams. MVR group addresses cannot fall within the reserved IP multicast
address range of 224.0.0.x.
â—† IGMP snooping and MVR share a maximum number of 1024 groups. Any
multicast streams received in excess of this limitation will be flooded to all ports
in the associated domain.
Example
The following example maps a range of MVR group addresses to a profile:
Console(config)#mvr profile rd 228.1.23.1 228.1.23.10
Console(config)#
mvr proxy-query-
interval
This command configures the interval at which the receiver port sends out general
queries. Use the no form to restore the default setting.
Syntax
mvr proxy-query-interval interval
no mvr proxy-query-interval
interval - The interval at which the receiver port sends out general queries.
(Range: 2-31744 seconds)
Default Setting
125 seconds
Command Mode
Global Configuration
Command Usage
This command sets the general query interval at which active receiver ports send
out general queries. This interval is only effective when proxy switching is enabled
with the mvr proxy-switching command.
