Chapter 1
| Initial Switch Configuration
Basic Configuration
– 55 –
subnet 192.168.255.0 netmask 255.255.255.0 {
range 192.168.255.160 192.168.255.200;
option routers 192.168.255.101;
option tftp-server-name "192.168.255.100"; #Default Option 66
option bootfile-name "bootfile"; #Default Option 67
}
class "Option66,67_1" { #DHCP Option 60 Vendor class
match if option vendor-class-identifier = "ECS4210-Series.cfg";
option tftp-server-name "192.168.255.101";
option bootfile-name "test";
}
Note:
Use “ECS4210-Series.cfg” for the vendor-class-identifier in the dhcpd.conf
file.
Enabling SNMP
Management Access
The switch can be configured to accept management commands from Simple
Network Management Protocol (SNMP) applications such as Edge-Core ECView
Pro. You can configure the switch to respond to SNMP requests or generate SNMP
traps.
When SNMP management stations send requests to the switch (either to return
information or to set a parameter), the switch provides the requested data or sets
the specified parameter. The switch can also be configured to send information to
SNMP managers (without being requested by the managers) through trap
messages, which inform the manager that certain events have occurred.
The switch includes an SNMP agent that supports SNMP version 1, 2c, and 3 clients.
To provide management access for version 1 or 2c clients, you must specify a
community string. The switch provides a default MIB View (i.e., an SNMPv3
construct) for the default “public” community string that provides read access to
the entire MIB tree, and a default view for the “private” community string that
provides read/write access to the entire MIB tree. However, you may assign new
views to version 1 or 2c community strings that suit your specific security
requirements (see the snmp-server view command).
Community Strings (for SNMP version 1 and 2c clients)
Community strings are used to control management access to SNMP version 1 and
2c stations, as well as to authorize SNMP stations to receive trap messages from the
switch. You therefore need to assign community strings to specified users, and set
the access level.
The default strings are:
◆ public - with read-only access. Authorized management stations are only able
to retrieve MIB objects.
◆ private - with read/write access. Authorized management stations are able to
both retrieve and modify MIB objects.
