Chapter 22
| Multicast Filtering Commands
IGMP Filtering and Throttling
– 567 –
â—† When receiving an IGMPv3 report message, the switch will send the access
request to the RADIUS server only when the record type is IS_EX
(MODE_IS_EXCLUDE) which excludes a source list, or TO_EX
(CHANGE_TO_EXCLUDE_MODE), and the source list is empty. Other type of
packets will not be authenticated.
â—† The first time the report is received and is being authenticated, regardless of
whether the authentication result succeeds or fails, this report will still be sent
to any configured multicatst router port.
â—† The attribute value pairs configured on the RADIUS server are shown below.
Example
Console(config)#interface ethernet 1/1
Console(config-if)#ip igmp query-drop
Console(config-if)#
show ip igmp filter This command displays the global and interface settings for IGMP filtering.
Syntax
show ip igmp filter [interface interface]
interface
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-12/28)
port-channel channel-id (Range: 1-8/12)
Default Setting
None
Command Mode
Privileged Exec
Table 119: RADIUS Server AVPs
Attribute Name AVP Type Entry
USER_NAME 1 User MAC address
USER_PASSWORD 2 User MAC address
NAS_IP_ADDRESS 4 Switch IP
NAS_PORT 5 User port
FRAMED_IP_ADDRESS 8 Multicast group IP
