Chapter 19 | VLAN Commands
Configuring L2CP Tunneling
– 485 –
Example
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel tpid 9100
Console(config-if)#
Related Commands
show interfaces switchport (394)
show dot1q-tunnel This command displays information about QinQ tunnel ports.
Command Mode
Privileged Exec
Example
Console(config)#dot1q-tunnel system-tunnel-control
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel mode access
Console(config-if)#interface ethernet 1/2
Console(config-if)#switchport dot1q-tunnel mode uplink
Console(config-if)#end
Console#show dot1q-tunnel
Port Mode TPID (hex)
-------- ------ ----------
Eth 1/ 1 Access 8100
Eth 1/ 2 Uplink 8100
Eth 1/ 3 Normal 8100
.
.
.
Related Commands
switchport dot1q-tunnel mode (483)
Configuring L2CP Tunneling
This section describes the commands used to configure Layer 2 Protocol Tunneling
(L2PT).
Table 100: L2 Protocol Tunnel Commands
Command Function Mode
l2protocol-tunnel tunnel-
dmac
Configures the destination address for Layer 2 Protocol
Tunneling
GC
switchport
l2protocol-tunnel
Enables Layer 2 Protocol Tunneling for the specified
protocol
IC
show l2protocol-tunnel Shows settings for Layer 2 Protocol Tunneling PE
