Chapter 23
| LLDP Commands
– 621 –
Example
Note that an IP phone or other end-node device which advertises LLDP-MED
capabilities must be connected to the switch for information to be displayed in the
“Device Class” field.
Console#show lldp info remote-device
LLDP Remote Devices Information
Interface Chassis ID Port ID System Name
--------- ----------------- ----------------- ---------------------
Eth 1/1 00-1A-7E-AC-2B-12 00-1A-7E-AC-2B-13
Console#show lldp info remote-device detail ethernet 1/1
---------------------------------------------------------------
Local Port Name : Eth 1/1
Chassis Type : MAC Address
Chassis ID : 00-1A-7E-AC-2B-12
Port ID Type : MAC Address
Port ID : 00-1A-7E-AC-2B-13
System Name :
System Description : Managed 24G+2GT+2GSFP Switch
Port Description : Ethernet Port on unit 1, port 1
SystemCapSupported : Bridge
SystemCapEnabled : Bridge
Remote Management Address :
192.168.1.20 (IPv4)
Remote Port VID : 1
Remote VLAN Name :
VLAN-1 : DefaultVlan
Remote Protocol Identity (Hex) :
88-CC
Remote MAC/PHY configuration status :
Remote port auto-neg supported : Yes
Remote port auto-neg enabled : Yes
Remote port auto-neg advertised cap (Hex) : 0000
Remote port MAU type : 6
Remote Power via MDI :
Remote power class : PSE
Remote power MDI supported : Yes
Remote power MDI enabled : Yes
Remote power pair controllable : No
Remote power pairs : Spare
Remote power classification : Class1
Remote Link Aggregation :
Remote link aggregation capable : Yes
Remote link aggregation enable : No
Remote link aggregation port id : 0
Remote Max Frame Size : 1518
Console#
