Configuring the Switch
3-6
3
IP Filter Configures IP addresses that are allowed management access 6-26
Port 8-1
Port Information Displays port connection status 8-1
Trunk Information Displays trunk connection status 8-1
Port Configuration Configures port connection settings 8-3
Trunk Configuration Configures trunk connection settings 8-3
Trunk Membership Specifies ports to group into static trunks 8-7
LACP Link Aggregation Control Protocol 8-8
Configuration Allows ports to dynamically join trunks 8-8
Aggregation Port Configures parameters for link aggregation group members 8-10
Port Counters Information Displays statistics for LACP protocol messages 8-13
Port Internal Information Displays settings and operational state for the local side 8-14
Port Neighbors Information Displays settings and operational state for the remote side 8-16
Port Broadcast Control Sets the broadcast storm threshold for each port 8-17
Trunk Broadcast Control Sets the broadcast storm threshold for each trunk 8-17
Mirror Port Configuration Sets the source and target ports for mirroring 8-19
Rate Limit 8-20
Input Port Configuration Sets the input rate limit for each port 8-20
Input Trunk Configuration Sets the input rate limit for each trunk 8-20
Output Port Configuration Sets the output rate limit for each port 8-20
Output Trunk Configuration Sets the output rate limit for each trunk 8-20
Port Statistics Lists Ethernet and RMON port statistics 8-22
Address Table 9-1
Static Addresses Displays entries for interface, address or VLAN 9-1
Dynamic Addresses Displays or edits static entries in the Address Table 9-2
Address Aging Sets timeout for dynamically learned entries 9-4
Spanning Tree 10-1
STA Spanning Tree Algorithm
Information Displays STA values used for the bridge 10-3
Configuration Configures global bridge settings for STP, RSTP and MSTP 10-6
Port Information Displays individual port settings for STA 10-10
Trunk Information Displays individual trunk settings for STA 10-10
Table 3-2 Switch Main Menu (Continued)
Menu Description Page
