Navigating the Web Browser Interface
3-7
3
Port Configuration Configures individual port settings for STA 10-13
Trunk Configuration Configures individual trunk settings for STA 10-13
MSTP Multiple Spanning Tree Algorithm
VLAN Configuration Configures priority and VLANs for a spanning tree instance 10-16
Port Information Displays port settings for a specified MST instance 10-19
Trunk Information Displays trunk settings for a specified MST instance 10-19
Port Configuration Configures port settings for a specified MST instance 10-20
Trunk Configuration Configures trunk settings for a specified MST instance 10-20
VLAN 11-1
802.1Q VLAN 11-1
GVRP Status Enables GVRP VLAN registration protocol 11-4
Basic Information Displays information on the VLAN type supported by this switch 11-4
Current Table Shows the current port members of each VLAN and whether or
not the port is tagged or untagged
11-5
Static List Used to create or remove VLAN groups 11-6
Static Table Modifies the settings for an existing VLAN 11-7
Static Membership by Port Configures membership type for interfaces, including tagged,
untagged or forbidden
11-9
Port Configuration Specifies default PVID and VLAN attributes 11-10
Trunk Configuration Specifies default trunk VID and VLAN attributes 11-10
802.1Q Tunnel
Configuration
Enables 802.1Q (QinQ) Tunneling 11-16
Tunnel Port Configuration Sets the tunnel mode for an interface 11-17
Tunnel Trunk Configuration Sets the tunnel mode for an interface 11-17
Private VLAN 11-18
Status Enables or disables the private VLAN 11-19
Link Status Configures the private VLAN 11-19
Protocol VLAN 11-20
Configuration Creates a protocol group, specifying the supported protocols 11-20
Port Configuration Maps a protocol group to a VLAN 11-21
Table 3-2 Switch Main Menu (Continued)
Menu Description Page
To Next Page
