IGMP Snooping Internet Group Management Protocol – Snooping 15-2
IGMP Configuration Enables multicast filtering; configures parameters for multicast
query
15-3
IGMP Immediate Leave Configures immediate leave for multicast services no longer
required
15-5
Multicast Router
Port Information
Displays the ports that are attached to a neighboring multicast
router for each VLAN ID
15-6
Static Multicast Router
Port Configuration
Assigns ports that are attached to a neighboring multicast router 15-7
IP Multicast Registration
Table
Displays all multicast groups active on this switch, including
multicast IP addresses and VLAN ID
15-8
IGMP Member Port Table Indicates multicast addresses associated with the selected
VLAN
15-8
DNS Domain Name Service 16-1
General Configuration Enables DNS; configures domain name and domain list; and
specifies IP address of name servers for dynamic lookup
16-1
Static Host Table Configures static entries for domain name to address mapping 16-3
Cache Displays cache entries discovered by designated name servers 16-5
DHCP Dynamic Host Configuration Protocol 17-1
Relay Configuration Specifies DHCP relay servers; enables or disables relay service 17-1
Server Configures DHCP server parameters 17-2
General Enables DHCP server; configures excluded address range 17-3
Pool Configuration Configures address pools for network groups or a specific host 17-4
IP Binding Displays addresses currently bound to DHCP clients 17-9
VRRP Virtual Router Redundancy Protocol 18-2
Group Configuration Configures VRRP groups, including virtual interface address,
advertisement interval, preemption, priority, and authentication
18-2
Global Statistics Displays global statistics for VRRP protocol packet errors 18-7
Group Statistics Displays statistics for VRRP protocol events and errors on the
specified VRRP group and interface
18-8
IP Internet Protocol 19-1
General 19-4
Global Settings Enables or disables routing, specifies the default gateway 19-4
Routing Interface Configures the IP interface for the specified VLAN 19-5
