Configuring the Switch
3-10
3
ARP Address Resolution Protocol 19-8
General Sets the protocol timeout, and enables or disables proxy ARP for
the specified VLAN
19-9
Static Addresses Statically maps a physical address to an IP address 19-11
Dynamic Addresses Shows dynamically learned entries in the IP routing table 19-12
Other Addresses Shows internal addresses used by the switch 19-13
Statistics Shows statistics on ARP requests sent and received 19-14
Statistics 19-16
IP Shows statistics for IP traffic, including the amount of traffic,
address errors, routing, fragmentation and reassembly
19-16
ICMP Shows statistics for ICMP traffic, including the amount of traffic,
protocol errors, and the number of echoes, timestamps, and
address masks
19-17
UDP Shows statistics for UDP, including the amount of traffic and
errors
19-19
TCP Shows statistics for TCP, including the amount of traffic and TCP
connection activity
19-20
Routing 19-21
Static Routes Configures and display static routing entries 19-21
Routing Table Shows all routing entries, including local, static and dynamic
routes
19-22
Routing Protocol 20-1
RIP Routing Information Protocol 20-2
General Settings Enables or disables RIP, sets the global RIP version and timer
values
20-3
Network Addresses Configures the network interfaces that will use RIP 20-5
Interface Settings Configures RIP parameters for each interface, including send
and receive versions, message loopback prevention, and
authentication
20-6
Redistribute Configuration Imports external routing information from other routing domains
into the autonomous system
20-9
Statistics Displays general information on update time, route changes and
number of queries, as well as a list of statistics for known
interfaces and neighbors
20-11
Table 3-2 Switch Main Menu (Continued)
Menu Description Page
To Next Page
