Option Description
F9 Job Manager Perform job-related tasks such as creating, activating, copying, or editing
a job.
This is also where you can select the Connect for Transfer button that
enables you to transfer jobs between the analyzer and the PC.
F10 Job Flow Select optional parameters to include as part of the current alignment
job. This is available only in Advanced mode.
Parameters include thermal growth, foot pre-check, live move
orientation, live move alerts, and an option to review alignment results.
F11 Print Job Print a summary report of the alignment job to AMS Machinery Manager
or to a memory card inserted into the analyzer.
F12 Job Reset Reset the job data by clearing all stored data, loading default values, or by
loading default tolerance values.
Vertical alignment
ALT2 keys - vertical alignmentFigure 7-4:
Advanced Laser Alignment
168 MHM-97432 Rev 7
