Option Description
F1 Notes Create, add, or remove notes from an alignment job or the analyzer.
Notes can be saved with the job to help you remember important
information about a machine.
F2 Machine Config Select the machine components for the alignment job.
F3 Set Angle Advance Define the fine and coarse incremental adjustments to be applied to the
angular position of the laser fixtures during data acquisitions and live
move operations.
F4 Set Mode Select Standard or Averaging mode of operation.
Standard is most often used for vertical alignments.
In Standard mode, the current reading is obtained directly from the laser
fixtures. In Averaging mode, multiple data sets are sampled to reduce the
noise by averaging the last 20 acquired readings.
F5 Set Sample Rate Set the number of samples to average to generate a single reading. You
can choose from 1-25 samples. 2 is the default.
F6 Intentionally blank.
F7 Exit Laser Align Exit the Laser Align Application and return to the home screen.
F8 Head Config Specify or view the placement of the laser and sensor.
This is also where you can check the status of the laser and sensor.
F9 Job Manager Perform job-related tasks such as creating, activating, copying, or editing
a job.
This is also where you can select the Connect for Transfer button that
enables you to transfer jobs between the analyzer and the PC.
F10 Review Results Enable reviewing of alignment results.
F11 Print Job Print a summary report of the alignment job to AMS Machinery Manager
or to a memory card inserted into the analyzer.
F12 Job Reset Reset the job data by clearing all stored data, loading default values, or by
loading default tolerance values.
Advanced Laser Alignment
MHM-97432 Rev 7 169
