WARNING!
• Use only Emerson-supplied power supplies and chargers approved for use with the CSI
2140 and Emerson battery packs. Using any power supplies and chargers other than
approved Emerson power supplies and battery packs could not only void the warranty,
but will also most likely damage the analyzer or the battery pack.
• Ensure the air vents on the external CSI 2140 Battery Charger are clear and uncovered.
• When charging the CSI 2140 with the battery pack or the battery pack by itself, ensure
the ambient temperature where charging is occurring is 50° F to 95° F (10° C to 35° C).
• Charge the battery pack only in a non-hazardous area.
Prerequisites
Remove the battery pack from the analyzer. See Section 2.7.6.
Procedure
1.
With the metal contacts on the battery pack facing up, lift the battery pack over the
raised edges and then slide the battery pack into the charger.
Battery pack inserted into the external CSI 2140 Battery ChargerFigure 2-8:
A. Raised edges
B.
Battery pack
2. Insert the power supply cord into an outlet and into the connector on the back of
the external CSI 2140 Battery Charger.
Charging begins and the LED is amber. The battery pack is fully charged when the
battery LED on the external CSI 2140 Battery Charger changes from amber to green.
To check the progress, press the button on the battery pack next to the 5 LEDs. Each
LED represents approximately 20 percent charge.
Introduction to the analyzer
18 MHM-97432 Rev 7
