Note
If you have not activated a route, the Route Management screen opens when you press F8
Route from the analyzer Home screen.
2. From the Route Management screen, use the up and down arrow keys to select a
route in the list.
3.
Press F1 Select/Unselect Route to select the route.
A checkmark appears next to the selected route.
4. Press F3 Activate Route.
The Route Data Collection screen appears. The first equipment and measurement
point defined in the route are activated and displayed.
Activate equipment in a route
By default, the analyzer activates the first equipment and measurement point in the route.
You can activate other equipment in a route without collecting data for the previous
equipment.
Procedure
1. Activate a route.
2. From the Route Data Collection screen, press F3 Equip List.
3. Press F8 or F9 to select other equipment.
Under Measurement Points, a checkmark shows the points with data. You can also
activate a specific point for the selected equipment.
4. Press F2 Activate Equip.
The Route Data Collection screen appears. The selected equipment and its first
measurement point display.
Activate the next unmeasured route point on the equipment
1. Activate a route.
2. From the Route Data Collection screen, press F3 Equip List.
3. Ensure the appropriate equipment is selected in the top pane.
Under Measurement Points, a checkmark appears next to each point that has
collected data.
4. Press F6 Next Un-Measured Point.
The Route Data Collection screen appears.
Route
76 MHM-97432 Rev 7
