• mA Output Damping = 2 seconds
Result: A change in the mass flow rate will be reflected in the mA Output over a time period that is greater
than 3 seconds. The exact time period is calculated by the transmitter according to internal algorithms which
are not configurable.
8.4.6 Configure mA Output Fault Action
Display Menu → Configuration → Inputs/Outputs → Channel B → I/O Settings → Fault Action
ProLink III Device Tools → Configuration → I/O → Outputs → mA Output x → Fault Action
Field communicator Device Settings → Inputs/Outputs → mA Output x → mAO x Fault Settings
mA Output Fault Action controls the behavior of the mA Output if the transmitter detects a fault condition.
Important
• The fault action is implemented only if Alert Severity is set to Failure. If Alert Severity is set to any other
option, the fault action is not implemented.
• For some faults only: If Fault Timeout is set to a non-zero value, the transmitter will not implement the
fault action until the timeout has elapsed.
Procedure
1. Set mA Output Fault Action as desired.
Default: Downscale
Important
If you set mA Output Fault Action to None, the mA Output will be controlled by the setting of Process
Variable Fault Action. In most cases, if you set mA Output Fault Action to None, you should also set
Process Variable Fault Action to None.
2. If you set mA Output Fault Action to Upscale or Downscale, set mA Output Fault Level to the signal
that the mA Output will produce during a fault.
Options for mAO Fault Action and mAO Fault Level
Option
mA Output behavior mA Output Fault Level
Upscale Goes to the configured fault level Default: 22.0mA
Range: 21.0 to 23.0mA
Downscale (default) Goes to the configured fault level Default: 2.0 mA
Range: 1.0 to 3.6 mA
Internal Zero Goes to the mA Output level associated with a
process variable value of 0 (zero), as determined
by Lower Range Value and Upper Range Value
settings
Not applicable
None Determined by the setting of Process Variable
Fault Action
Not applicable
Configuration and Use Manual Integrate the meter with the control system
MS-00809-0200-1600 May2024
Configuration and Use Manual 105
