Table A-1: Status LED and device status
Status LED condition Device status
Solid green No alerts are active.
Solid yellow One or more alerts are active with Alert Severity = Out of Specification,
Maintenance Required, or Function Check.
Solid red One or more alerts are active with Alert Severity = Failure.
Flashing yellow (1Hz) Auto zero or SMV test in progress
Flashing green An auto zero is being performed.
Status LED off Transmitter is not receiving power.
Display is not seated or not functioning properly.
LCD panel
In normal operation, the LCD panel shows the current value of the display variables, and their measurement
units.
The LCD panel also provides access to the display menus and alert information. From the display menus, you
can:
• View the current configuration and make configuration changes.
• Perform procedures such as loop testing and zero verification.
• Run batches.
The alert information allows you to see which alerts are active, acknowledge the alerts individually or as a
group, and to see more detailed information for individual alerts.
A.2 Access and use the display menus
The display menus allow you to perform most configuration, administration, and maintenance tasks.
The four switches, ⇦⇧⇩⇨, are used to navigate the menus, make selections, and enter data.
Procedure
1. Observe the action bar at the bottom of the LCD panel.
The action bar displays Menu⇨.
2. Hold your thumb or finger over the ⇨ membrane switch to activate it.
The top-level menu is displayed.
3. Navigate the menus using the four membrane switches:
• Activate ⇧ or ⇩ to scroll to the previous or next item in the menu.
• Activate and hold ⇧ or ⇩ (approximately 1 second) to scroll rapidly through numbers or menu
options.
• Activate ⇨ to drill down to a lower menu or to select an option.
• Activate and hold ⇨ to save and apply your action.
• Activate ⇦ to return to the previous menu.
• Activate and hold ⇦ to cancel your action.
The action bar is updated with context-sensitive information. The ⇨ and ⇦ symbols indicate the
associated membrane switch.
