4.5 Configure density measurement
The density measurement parameters control how density is measured and reported. Density measurement is
used with mass flow rate measurement to determine liquid volume flow rate.
4.5.1 Configure Density Measurement Unit
Display Menu → Configuration → Process Measurement → Density → Units
ProLink III Device Tools → Configuration → Process Measurement → Density → Density Unit
Field communicator Device Settings → Process Configuration → Density → Density Unit
Density Measurement Unit controls the measurement units that will be used in density calculations and
reporting.
Restriction
If the API Referral application is enabled, you cannot change the density measurement unit here. The density
measurement unit is controlled by the API table selection.
Procedure
Set Density Measurement Unit to the option you want to use.
Default: g/cm
3
(grams per cubic centimeter)
Options for Density Measurement Unit
The transmitter provides a standard set of measurement units for Density Measurement Unit. Different
communications tools may use different labels.
Unit description
Label
Display ProLink III Field communicator
Specific gravity
(1)
SGU SGU SGU
Grams per cubic centimeter g/cm3 g/cm3 g/Cucm
Grams per liter g/L g/l g/L
Grams per milliliter g/mL g/ml g/mL
Kilograms per liter kg/L kg/l kg/L
Kilograms per cubic meter kg/m3 kg/m3 kg/Cum
Pounds per U.S. gallon lb/gal lbs/USgal lb/gal
Pounds per cubic foot lb/ft3 lbs/ft3 lb/Cuft
Pounds per cubic inch lb/in3 lbs/in3 lb/CuIn
Degrees API
(2)
API API degAPI
Short ton per cubic yard STon/yd3 sT/yd3 STon/Cuyd
(1) Non-standard calculation. This value represents line density divided by the density of water at 60°F
(15.6°C).
(2) Non standard calculation, unless the API referral application is enabled. Calculated from line density instead
of specific gravity.
Configuration and Use Manual Configure process measurement
MS-00809-0200-1600 May2024
Configuration and Use Manual 41
