480 Eos Family Operations Manual
Eos allows you to use any sACNuniverses from 1-63,999.The number of universes that can be used
at a time is limited to a block of 256 contiguous universes. The address range equals 1 to
32,767,488, which is 63,999 times 512.
Eos and the Net3 Gateways support two versions of sACN, the draft version and the final ratified ver-
sion. The ratified version is outputted by default unless this is selected.
Net2-EDMX
This sets the control priority for EDMX data from this desk. The valid range for this setting is 20 (low-
est) to 1 (highest). This is the reverse of sACN.
Avab UDP
This sets the subnet for Avab UDP data from this desk. The priority levels range from 0-200. The
default is 0, which is no priority level. 1 is the lowest priority level and 200 is the highest. When set to
no priority level (0), the data will merge according to HTP.
A backup desk will receive its Avab UDP priority level from the primary. The backup will then output
at one priority higher than the primary, unless the primary was set to the highest priority of 200.
ArtNet
This sets the subnet for ArtNet data from this desk. The valid ArtNet Start range for this setting is 0-
15.
Broadcast Type
Directed Broadcast - Broadcast packets are directed to a subnet based on the IP address and
subnet mask of the sender.
Limited Broadcast - The limited broadcast address is 255.255.255.255. It is limited because
routers will never forward datagrams with that destination address. This means that data-
grams with the limited broadcast address are confined to the particular network segment on
which they originate.
Backup Takes Over At Higher Priority
This enables the backup device in a multi-console system to take over at one priority higher than the
master if the master goes offline.
Backup Automatically Takes Control
Switches to the backup automatically if the primary should go offline.
Allowed Output Addresses
A range or ranges of addresses that can be assigned to limit the number of output addresses. The
default setting is to allow addresses 1 through 32767488.
Interface Protocols
MultiConsole
Clicking in the enable box will allow for multiconsole communication on the selected port. See Multi-
console and Synchronized Backup (on page455).
