Page #517 background imageLoading...
Page #517 background image
Show Control 515
Relay Outputs
Eos Family consoles can trigger relay outputs on Net3 I/O Gateways and on the built-in relay output
(when available). Relay outputs are also often called remote triggers, contact closures, or contact out-
puts. Relay outputs are controlled by external links in cues and submasters only.
Note: You enter relay information in the live or blind displays. This is not a Show Control
display function.
For Example:
[Live] [Cue] [1] {Execute} {Relay} [1] [/] [2] {On} [Enter] - 1 is the ACN Group ID of the
I/O Gateway or built-in relay output and the 2 is the relay output address.
