ETC Element 2 Operating Manual

554 Eos Family Operations Manual
OSC Method Arguments Examples/Comments
/eos/cue number of cue to select /eos/cue=1.5
/eos/cue/<list number> number of cue to select (in the specified cue list) /eos/cue/1=1.5
/eos/cue/<list number>/<cue number>
number of cue part to select (in the specified cue
list and cue number)
/eos/cue/1/1.5=2
Run Cues
/eos/cue/fire number of cue to run /eos/cue/fire=1
/eos/cue/<cue number>/fire
number for button edge: 1.0=down, 0.0=up
(optional)
/eos/cue/1.5/fire
/eos/cue/<list number>/<cue number>/fire
number for button edge: 1.0=down, 0.0=up
(optional)
/eos/cue/1/1.5/fire
/eos/cue/<list number>/<cue num-
ber>/<part number>/fire
number for button edge: 1.0=down, 0.0=up
(optional)
/eos/cue/1/1.5/2/fire
Cue Information Sent byEos– see Implicit OSC Output (on page558) for more information
/eos/out/active/cue/<list>/<cue>
Float argument with percent complete
0.0=started, 1.0 complete
/eos/out/active/cue/5/1=0.75
Updated once per second
/eos/out/active/cue
Float argument with percent complete
0.0=started, 1.0 complete
/eos/out/active/cue=0.75
Updated once per second
/eos/out/active/cue/text
String argument with descriptive text about active
cue
/eos/out/active/cue/text= “1/1 Label
5.00 100%”
/eos/out/pending/cue/<list>/<cue> None /eos/out/pending/cue/5/1.5
/eos/out/pending/cue/<list>/<cue>/text
String argument with descriptive text about active
cue
/eos/out/pending/cue/text= “1/1.5
Label 5.00”

ETC Element 2 Specifications

General

DMX Outputs	2
Touchscreen	Yes
Networking	Ethernet
Type	Lighting Control Console
Master Faders	2
Encoders	4
Ethernet Ports	2
USB Ports	4
Video Output	DisplayPort
Power Input	100-240VAC, 50/60Hz
Power Supply	Internal
Control Channels	6144
Output	Art-Net
Display	Multi-Touch LCD
Storage	Solid State Drive (SSD)
