558 Eos Family Operations Manual

Implicit OSC Output

When UDP transmit is enabled, certain OSC commands are sent out as appropriate. These events are

typically generated as the target changes or in response to user input.

Command Lines

“/eos/out/user/<number>/cmd”, <string argument with current command line text for the

current console user>

“/eos/out/cmd”, <string argument with current command line text>

OSC Settings

“/eos/out/user”, <integer argument with current OSC user ID>

“/eos/out/wheel”, <float argument with current OSC wheel mode: 0.0=Coarse, 1.0=Fine>

“/eos/out/switch”, <float argument with current OSC switch mode: 0.0=Coarse, 1.0=Fine>

Active Channels and Parameters

“/eos/out/active/chan”, <string argument with active channels and current value from the 1st

channel>

“/eos/out/active/wheel/<number>, <string argument with parameter name and current value

from the 1st channel>

Note: This allows you to create a ML Controls style interface via OSC. For example, on the

OSC-enabled device, setup 10 wheels (/eos/active/wheel/<1-10>) with matching labels.If

using in conjunction with “/eos/active/switch/<number>”, you should still use “/ eos-

/out/active/wheel/<number>” to display feedback for that switch

Active Cue

Note: Updated once per second.

“/eos/out/active/cue/<cue list number>/<cue number>”, <float argument with percent com-

plete (0.0-1.0)>

“/eos/out/active/cue”, <float argument with percent complete (0.0-1.0)>

“/eos/out/active/cue/text”, <string argument with descriptive text about the active cue, ex:

“1/ 2.3 Label 0:05 75%”>

“/eos/out/pending/cue/<cue list number>/<cue number>”

“/eos/out/pending/cue/text”, <string argument with descriptive text about the pending cue,

ex: “1/2.4 Label 0:30”>

OSC Direct Select Banks

“/eos/out/ds/<index>”, <string argument with descriptive text for the OSC direct select at

<index>: target name, page number, and mode>>

“/eos/out/ds/<index>/<button index>”, <string argument with button label for OSC direct

select at <index> for button <button index>>
