System Basics 77
Effects - purple
Snapshots - red
Magic Sheets - magenta
Scenes - green
Custom - light gray
If there are more items than can be viewed at once, you may view subsequent pages by using the
page touchbuttons ({p}, {q}) by the direct selects. Hold a page button down and type a number to
jump to a specific direct select.
When storing to direct selects (groups, palettes, presets, and so on), you may store directly to them
by pressing [Record] {Direct Select Key}.
When the direct select is chosen and on the command line, it will have a gold border around it. If con-
tent is available for selected channels, the tile is highlighted. An unrecorded direct select will have a
dark background with dark gray text.
Note: To adjust the brightness of the direct selects, use the Color Brightness fader in
Setup. When the fader is set to 0, the color coding is removed. See Direct Selects Brightness
(on page168) for more information.
You can record decimal inserts to a direct select ({Group 7.1}, {Color Palette 15.5}, {Preset 6.94}, and
so on). Use the {Increment} setting in the Direct Selects Configuration Menu (below) to set how the
numbers will display.
For Example:
Assume you have stored color palette 1 (button 1), color palette 1.1 (button 2), and color
palette 3 (button 3). If you record color palette 2, it will appear in the slot just after color
palette 1.1 and color palette 3 will be bumped one slot to the right. This will continue until
an open slot can absorb the displaced target.
To change the direct select type, press the {Select} button. See Direct Selects Configuration Menu
(below) for more information about the {Select} button.
Direct Selects Configuration Menu
You have considerable flexibility in how you organize the direct selects by using the options in the
configuration menu.
To access the configuration menu, right click or tap on the direct select's tab to see the con-
figuration menu.
