Programming manual.
CNC 8070
1.
CREATING A PROGRAM.
List of statements and instructions.
·46·
(REF: 1709)
Probing.
Probing canned cycles. ·M· model (milling).
Probing canned cycles. ·T· model (lathe).
#TSYNC Spindle synchronization. Synchronization of the theoretical coordinate. 22.1.11
#UNLINK Cancel the electronic coupling (slaving) of axes. 22.1.7
#UNPARK Unpark an axis 22.1.8
#UNSYNC Spindle synchronization. Decouple the spindles. 22.1.11
#VIRTAX ON Activate the virtual tool axis. 21.1
#VIRTAX OFF Cancel the virtual tool axis. 21.2
#WAIT Channels. It waits for a mark to be activated in the indicated channel. 22.1.19
#WAIT FOR Wait for an event. 22.1.22
#WARNING Display a warning on the screen. 22.1.2
#WARNINGSTOP Display a warning on the screen and interrupt the program. 22.1.2
Instruction Meaning
#SELECT PROBE Probe selection.
#PROBE 1 Tool calibration (dimensions and wear).
#PROBE 2 Probe calibration.
#PROBE 3 Surfacing measuring.
#PROBE 4 Outside corner measuring.
#PROBE 5 Inside corner measuring.
#PROBE 6 Angle measurement on the abscissa axis.
#PROBE 7 Outside corner and angle measurement.
#PROBE 8 Hole measuring.
#PROBE 9 Circular boss measuring.
#PROBE 10 Rectangular part centering.
#PROBE 11 Circular part centering.
#PROBE 12 Tabletop probe calibration.
#PROBE 1 Tool calibration.
#PROBE 2 Tabletop probe calibration.
#PROBE 3 Part measurement along the ordinate axis.
#PROBE 4 Part measurement along the abscissa axis.
