18-3. Selecting Reference Signal
The switcher provides reference input, its loop-through and output connectors in the GENLOCK
section on the rear panel.
18-3-1. To Set Reference Input
(1) Press the MENU button, then press the 7/SETUP button to display the SETUP top menu.
Turn F1 to select SYSTEM, then press F1 or the PAGE DOWN button to open the
[SETUP- SYSTEM] menu.
(2) Turn F1 to select REF I/O, then press F1 or the PAGE DOWN button to open the
[SETUP - SYSTEM - REF IN] menu.
(3) Turn F1 to select a reference signal to be input to the switcher between Black Burst and
Tri-level Sync.
SYSTEM : TYPE : : 1/2
REF IN : =BB : :
18-3-2. To Set Reference Output
(1) Press the PAGE DOWN button in the [SETUP-SYSTEM-REF IN] menu to go to the
[SETUP- SYSTEM-REF OUT] menu.
(2) Turn F1 to select a reference signal to be output from the switcher between Black Burst
and Tri-level Sync.
(3) You can adjust the horizontal phase of the reference signal under the H PHS item and the
vertical phase under the V PHS item.
SYSTEM : TYPE : H PHS : V PHS : : 2/2
REF OUT : =BB : =0 : =0 : :
18-4. Adjusting Video Signal Levels
18-4-1. Proc Amp
The switcher provides the following Proc Amp features.
(1) Press the MENU button, then press the 7/SETUP button to display the SETUP top menu.
Turn F1 to select INPUT, then press F1 or the PAGE DOWN button to open the [SETUP-
INPUT] menu.
(2) Turn F1 to select PROC AMP, then press F1 or the PAGE DOWN button to open the
[SETUP-INPUT-PROC AMP] menu.
(3) Turn F1 to select the input to be adjusted.
(4) Turn F4 to set ENABLE to ON to enable the PROC AMP feature.
(5) You can adjust the luminance level under the Y-Lv item and the black level under the
BLK-Lv item.
INPUT :SELECT : Y-Lv :BLK-Lv :ENABLE : 1/3
PROC AMP: =IN04 : =1.00 : =0 : =ON :
(6) Press the PAGE DOWN button to go to PAGE 2.
(7) You can adjust the chrominance level under the Pb-Lv item and the Pr-Lv item.
INPUT :SELECT : Pb-Lv : Pr-Lv :ENABLE : 2/3
PROC AMP: =IN04 : =1.00 : =1.00 : =ON :
To Next Page
