6. Video Sources
6-1. How to Give Name to Sources
Signals available for selection on the PGM/PST bus and the KEY/AUX bus can be assigned
user specific names, to make them easier to identify for operators. User names can be given to
input signals, internally generated black matt and matt signals, and still pictures. Follow the
procedure below to name a signal.
(1) Press the MENU button and then press the 7/SETUP button to display the SETUP menu’s
top page.
(2) Turn F1 to select INPUT. Then press F1 or the PAGE DOWN button to display the [SETUP-
INPUT] menu.
(3) Turn F1 to select RENAME. Press F1 or the PAGE DOWN button to display the [SETUP-
INPUT- RENAME] menu.
SETUP :>SIGNAL >PROC AMP>RENAME >ASSIGN
INPUT :
(4) Turn F1 to select a signal at the SELECT item. (See the table below.)
INPUT :SELECT :SHORT : LONG NAME (MV) : 1/1
RENAME : =IN04 : =IN04 : =INPUT04 :
SELECT
SHORT
default
setting
LONG NAME
default setting
(*1)
Signal description
BLACK BLAK BLACK Black signal
IN01 to IN04 IN01 to IN04
INPUT01 to
INPUT04
SDI video input to rear connectors 1-4
STILL1,
STILL2
STL1, STL 2 STILL1, STILL2 Still images 1 and 2
MATT MATT MATTE BUS matte color
CLBAR CLBR COLOR BAR Color bar
IN05 to IN12 IN05 - (*2) INPUT05 - (*2)
Optional video inputs on Slot A and Slot B
(See section 2-4.)
(*1) Long names are used for titles displayed on the multiviewer screen.
(*2) IN05 and following inputs are determined by the type and number of the installed input expansion card.
(5) To change the short name of a signal, use F2 to give it a name up to 4 characters in length,
entering the characters one by one. First, press F2 to highlight a character. When the latter
blinks, turn F2 to change it. Alphabet, numbers and symbols (ASCII characters) can be used
for names.
(6) To change the long name of a signal, use F3 to give it a name up to 8 characters in length,
entering the characters one by one. First, press F3 to highlight a character. When the latter
blinks, turn F3 to change it. Alphabet, numbers and symbols (ASCII characters) can be used
for names.
