10-3. Pattern Modify Example1 (Pattern 20)
This modification example adds a border effect to the background transition using Pattern 20.
(1) Select the signal used for the next transition in the PST bus.
(2) Press BKGD in the NEXT TRANSITION block.
(3) Press WIPE in the TRNSITION TYPE block.
(4) The [TRANS - BKGD] menu appears in the Menu Display. Press F3, enter "20" in the Keypad
and press ENT/STORE in the Keypad to select Pattern 20.
TRANS : RATE : LIMIT :PATTERN : 1/6
BKGD : =30 : =100.0: =20 :
(5) Press MENU to the right of the Menu Display (if it is not lit), and then press 4/WIPE in the
KEYPAD to display the WIPE menu.
(6) Turn F1 to select BORDER. Press F1 or the PAGE DOWN button.
WIPE :>BORDER >POS/ANGL>MULTI >SUB EFF
No.020 :>INIT
(7) The [WIPE - BORDER] menu appears. Turn F1 to select the signal used for the border under
the SIGNAL item. Select MATT in this example. Set the border width under the WIDTH item
and border softness under the SOFT item.
WIPE :SIGNAL : WIDTH : SOFT : : 1/2
BORDER : =MATT : =5.0 : =2.0 : :
(8) Press the PAGE DOWN button to go to PAGE 2. Turn F4 to select a border color from eight
standard colors. Press F4 to apply the selected color. If you want to adjust the selected color
or set the color by entering HSL values, turn F1, F2 and F3 to adjust values or press F1, F2
and F3, enter a value in the Keypad and then press ENT/STORE in the Keypad. Users can
also set these three parameters in the JOYSTICK block. (See section 4-2-4. "Changing
Settings or Values by Using the Joystick.")
WIPE : BORDER COLOR :RECALL : 2/2
BORDER :S=66.3 L=5.4 H=3.5 : >BLUE :
